How to add new bundles into pyAFQ (SLF 1/2/3 Example)

Authors
Affiliations
University of Washington
University of Washington

pyAFQ is designed to be customizable and extensible. This example shows how you can customize it to define a new bundle based on a definition of waypoint and endpoint ROIs of your design.

In this case, we add sub-bundles of the superior longitudinal fasciculus, based on work by Sami et al. 2024

from paths import afq_home
import os.path as op
import plotly
import numpy as np
from IPython.display import Image

from AFQ.api.group import GroupAFQ
import AFQ.api.bundle_dict as abd
import AFQ.data.fetch as afd
from AFQ.definitions.image import ImageFile, RoiImage
np.random.seed(1234)

1Get dMRI dataΒΆ

We will analyze twelve subjects from the Healthy Brain Network Processed Open Diffusion Derivatives dataset (HBN-POD2) Richie-Halford et al. (2022).

The data gets organized into a BIDS-compatible format.

_, study_dir = afd.fetch_hbn_preproc(['NDARAA948VFH'])

2Define custom BundleDict objectΒΆ

We define the bundles with include/exclude ROIs and specific cleaning parameters.

template_dir = op.join(afq_home, 'SLF_ROIs')
templates_afq = afd.read_templates(as_img=False)

# You can provide paths to the ROIs in the "include" and "exclude" keys of the bundle definition
bundles = abd.BundleDict({
    "L_SLF1": {
        "include": [template_dir + '/SFgL.nii.gz', template_dir + '/PaL.nii.gz'],
        "exclude": [templates_afq['SLFt_roi2_L']],
        "cross_midline": False,
        "mahal": {"clean_rounds": 20, "length_threshold": 4, "distance_threshold": 2}
    }
})

3Define GroupAFQ objectΒΆ

We configure the AFQ pipeline with predefined parameters and start the process.

brain_mask_definition = ImageFile(
    suffix="mask",
    filters={'desc': 'brain', 'space': 'T1w', 'scope': 'qsiprep'}
)

my_afq = GroupAFQ(
    bids_path=study_dir,
    preproc_pipeline="qsiprep",
    participant_labels=["NDARAA948VFH"],
    output_dir=op.join(study_dir, "derivatives", "afq_slf"),
    brain_mask_definition=brain_mask_definition,
    tracking_params={"n_seeds": 4, "directions": "prob", "odf_model": "CSD", "seed_mask": RoiImage()},
    segmentation_params={"parallel_segmentation": {"engine": "serial"}},
    bundle_info=bundles
)

my_afq.export("profiles")
INFO:AFQ:No stop mask given, using FA (or first scalar if none are FA)thresholded to 0.2
{'NDARAA948VFH': '/home/jovyan/data/tractometry/tractometry/HBN/derivatives/afq_slf/sub-NDARAA948VFH/ses-HBNsiteRU/dwi/sub-NDARAA948VFH_ses-HBNsiteRU_acq-64dir_desc-profiles_tractography.csv'}

4Visualize a montageΒΆ

We create montage visualizations of the SLF bundles.

montage = my_afq.group_montage("L_SLF1", (3, 4), "Sagittal", "left", slice_pos=0.5)
Image(filename=montage[0])
INFO:AFQ:Generating Montage...
  0%|          | 0/1 [00:00<?, ?it/s]
INFO:AFQ:Loading Volume...
INFO:AFQ:Loading Volume...
INFO:AFQ:Loading Stateful Tractogram...
/srv/conda/envs/notebook/lib/python3.11/site-packages/AFQ/utils/streamlines.py:93: UserWarning:

Pass ['to_space'] as keyword args. From version 2.0.0 passing these as positional arguments will result in an error.

INFO:AFQ:Generating colorful lines from tractography...
100%|β–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆ| 1/1 [00:06<00:00,  6.77s/it]
100%|β–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆβ–ˆ| 1/1 [00:06<00:00,  6.78s/it]

INFO:AFQ:Montage file already exists, skipping.
<IPython.core.display.Image object>

5Interactive bundle visualizationΒΆ

We export individual bundle figures as interactive HTML files.

bundle_html = my_afq.export("all_bundles_figure")
plotly.io.show(bundle_html["NDARAA948VFH"][0])
Loading...

6ReferencesΒΆ

  • Richie-Halford A, Cieslak M, Ai L, et al. An analysis-ready and quality controlled resource for pediatric brain white-matter research. Scientific Data. 2022. Richie-Halford et al. (2022)
